HSE-BSP21L Series

FEATURES
• 12VDC，0-10V Dimming.
• With Daylight Harvesting .
• Supports remote control via the HSE WISE APP.

Technical Specifications

Component Type

Integrated PIR Sensor

Input Voltage

DC 10-15V

Input Current

<20mA

Stand-by Power

DC 10V@<0.5W

Control Method

ON / OFF, DIM 0-10V

Control Device

HSE WISE APP

Bluetooth Transmit

30m / 98 ft

Radio Frequency

2.4GHz（2402~2480MHz）

Bluetooth Version

5.4

Detection Angle

120-360° Fersnel Lens

Mounting Heigh

<4m/13ft

Detection Range

Radius: 2-4m (6 .56-13.12ft)

Working Temp

-30°C to 60°C

IP Rating

IP20

Warranty

5 years
