HSE-BSP1H
DESCRIPTION
The HSE-BSP1H series sensors are Bluetooth wireless luminaire level
lighting control (LLLC) for commercial outdoor/indoor luminaires that
require a IP65/Wet Location. They are available with variety of di erent
style sockets.
FEATURES
• 12VDC，0-10V Dimming
• Remote control , APP control for BLE version.
• With Daylight Harvesting and Photocell Function.
• ONE for ALL Installations Parterning With Di erent Receptacles & Brackets.
The HSE-BSP1H series sensors are Bluetooth wireless luminaire level
lighting control (LLLC) for commercial outdoor/indoor luminaires that
require a IP65/Wet Location. They are available with variety of di erent
style sockets.
FEATURES
• 12VDC，0-10V Dimming
• Remote control , APP control for BLE version.
• With Daylight Harvesting and Photocell Function.
• ONE for ALL Installations Parterning With Di erent Receptacles & Brackets.
|
Part Number |
HSE-BSP1H |
|
Component Type |
Highbay Sensor |
|
Input Voltage |
12-24VDC, >50mA |
|
Input Current |
<30mA |
|
Dimming |
ON/OFF, 0-10V Dimming |
|
Bluetooth Transmit |
25M / 170.60ft |
|
Radio Frequency |
2.4GHz (2402 ~ 2480MHz) |
|
Bluetooth Version |
5.2 |
|
Installation Height |
15m / 49.21ft Max. |
|
Detection Distance |
≥3m / 9.84ft |
|
Detection Angle |
Fresnel Lens ≤ 120° Fersnel Lens |
|
Indoor / Outdoor Use |
Indoor |
|
Storage Temperature |
-30°C to 85°C, -22°F to 185°F |
|
IP Rating |
IP65 |
|
Warranty |
5 years warranty |
