HSE-XSP9H Series

FEATURES
• 12 VDC, 0 - 10V Dimming
• Remote control , APP control for BLE version.
• With Daylight Harvesting and Photocell Function.
• ONE for ALL Installations Parterning With Different Receptacles & Brackets.
• UFO high bay, Linear high bay, area light

Technical Specifications

Component Type

High - bay PIR Sensor

Input Voltage

DC 12-24V

Input Current

<30mA (Regular-Version)

<20mA (Bluetooth-Version)

Stand-by Power

DC10V@<0.5W

Control Method

DIM 0-10V

Control Device

  Remote Control & Manual Switches                                  & HSE WISE APP

Bluetooth Transmit

30m / 98ft

Radio Frequency

2.4GHz (2402~2480MHz)

Bluetooth Version

5.4

Detection Angle

≤120° Fersnel Lens

Mounting Height

12m / 39ft Max.

Detection Range

Radius: 3-7m (9.84-22.97ft)

Working Temp

-20℃ to +60℃

IP Rating

                                                              IP65

Warranty

5 years
