HSE-XSM11H Series
DESCRIPTION
This series of products is a high - bay sensor, with an installation height ≤15m, and is suitable for indoor and outdoor spaces such as warehouses, factories, and parking lots.
FEATURES
• 12VDC，0-10V Dimming.
• With Daylight Harvesting and Photocell Function.
• BLE Version with APP control & Regular Version with remote control both available.
• Application：Linear high bay, Linear strip, wrap.
This series of products is a high - bay sensor, with an installation height ≤15m, and is suitable for indoor and outdoor spaces such as warehouses, factories, and parking lots.
FEATURES
• 12VDC，0-10V Dimming.
• With Daylight Harvesting and Photocell Function.
• BLE Version with APP control & Regular Version with remote control both available.
• Application：Linear high bay, Linear strip, wrap.
Technical Specifications
Component Type | High - bay Microwave Sensor |
Input Voltage | DC 12-24V |
Input Current | <30mA (Regular-Version) <20mA (Bluetooth-Version) |
Stand-by Power | DC10V@<0.5W |
Control Method | DIM 0-10V |
Control Device | Remote Control & Manual Switches & HSE WISE APP |
Bluetooth Transmit | 30m / 98ft |
Radio Frequency | 2.4GHz (2402~2480MHz) |
Bluetooth Version | 5.4 |
Detection Angle | 30-150°（Without Glass Cover) |
Mounting Height | 15m/49.21ft Max. |
Detection Range | Radius: ≥3m / 9ft |
Working Temp | 40°C~+70°C |
IP Rating | IP65 (With Elbow) IP20 (No Elbow) |
Warranty | 5 years |
