HSE-XSM19L Series

FEATURES
• 12 VDC, 0 - 10V Dimming
• BLE Version with APP control & Regular Version with remote control both available.
• With Daylight Harvesting and Photocell Function.
• ONE for ALL Installations Parterning With Different Receptacles & Brackets.

Technical Specifications

Component Type	High - bay Microwave Sensor
Input Voltage	DC 10.5-15V
Input Current	<30mA
Stand-by Power	DC 10V@<0.5W
Control Method	ON/OFF, DIM 0-10V
Control Device	Remote Control & HSE WISE APP
Bluetooth Transmit	30m / 98 ft
Radio Frequency	2.4GHz（2402~2480MHz）
Bluetooth Version	5.4

Detection Angle	Wall Mounted 150°-360 °
Mounting Heigh	8m / 26.24ft Max.
Detection Range	Radius: 4-8m (13.12 - 26.24ft)
Working Temp	-30°C~+60°C
IP Rating	IP65
Warranty	5 years

Spec Sheet

HSE-SM19L HSE-BSM19L Series.pdf

Online browsing Download
