PRODUCTS > HSE-BSP4L-5

HSE-BSP4L-5

DESCRIPTION
• 12VDC Input with 0-10V dimming
• Bluetooth and regular version available;
• Square module part, with magnet for easy installation
• With quick connector
• Application：Panel, Troffer, Strip, Wrap

Technical Specifications

Component Type	Integrated Microwave Sensor
Input Voltage	10.5-15V DC (Supply Current >50mA)
Input Current	<40mA
Stand-by Power	DC 10V@<0.5W
Control Method	DIM 0-10V
Frequency	5.8GHz±75MHz
Microwave Power	<0.3mW
Mounting Height	≤4m/13ft Ceiling Mounted
Detection Range	Radius: 3-7m 9.84-22.97ft

Control Device	HSE WISE APP
Bluetooth Transmit	30m / 98ft
Radio Frequency	2.4GHz（2402~2480MHz)
Bluetooth Version	5.4
Working Temp	-30°C~+60°C
IP Rating	IP20

Spec Sheet

HSE-BSM4L-5.pdf

Online browsing Download
